Type-3 Pocket Bike Gearbox Transmission

Type-3 Gearbox Transmission for 47cc and 49cc Engines

The Type-3 Gearbox Transmission is engineered to restore the performance of 47cc and 49cc air-cooled 2-stroke engines. It is designed as a direct replacement for worn factory gearboxes, making it a practical choice for both pit bike restorations and custom pocket quad builds. This is one of the key mini bike & pocket bike parts to ensure efficient torque delivery from your engine to the ground, minimizing friction and improving durability.

Key Performance Features

This gearbox comes pre-installed with a 6-tooth sprocket, which is optimized for maintaining high speeds in small-displacement racing engines. It is compatible with T8F and BF05T chain standards, making it suitable for a variety of import pocket bikes and quads. The internal design features a precision 78mm clutch drum, which provides smooth engagement and reduces heat during operation.

Installation and Fitment

Designed as a direct bolt-on fit, the Type-3 Gearbox requires no modifications to your existing Cag or Daytona-style frame. When installing, it is recommended to allow approximately 1/2 inch of chain tension "play" to avoid excessive wear on the gearbox components. This ensures reliable performance and longevity of the gearbox.

Specifications

• Type: Type-3 Gearbox Transmission
• Sprocket Size: 6-Tooth
• Clutch Drum ID: 78mm
• Overall Height: 57mm
• Material: Cast Aluminum Housing / Steel Internals
• Chain Size: T8F or BF05T

Fitment

This gearbox is a direct fit for the following vehicles and engines:

• Pocket Bikes: Cagllari CAG, Daytona, MTA1, MTA2, Lucky 7
• Pocket Quads / ATVs: 47cc / 49cc Mini Quads & Dirt Bikes
• Go-Karts: Small-frame 2-stroke "Stand-up" Goped-style karts

Not sure it fits? Contact us with your scooter's make, model and year and we'll confirm the fit before you order.
